Introducing Paul Tube Fittings, a top-notch manufacturer and supplier of high-quality 904L Ball Valves right here in Houston, USA. With a strong focus on precision engineering and ensuring customer satisfaction, this company provides high-performance valve solutions that thrive in extreme and corrosive conditions. Specializing in 904L stainless steel, celebrated for its outstanding corrosion resistance, Paul Tube Fittings caters to industries like chemical processing, marine, oil & gas, and pharmaceuticals. By blending innovative manufacturing techniques with rigorous quality control, they’ve earned a reputation as a reliable name in fluid handling, delivering durable 904L ball valves throughout the United States.
When it comes to 904L ball valves, they’re crafted from stainless steel grade 904L, a high-alloy austenitic material that includes chromium, nickel, molybdenum, and copper. This unique blend provides remarkable resistance to strong acids, chloride stress corrosion, and pitting. The mechanical properties boast a tensile strength of about 490 MPa and a yield strength of 220 MPa, along with impressive toughness even in low temperatures. These valves are equipped with a solid ball mechanism, ensuring a tight shut-off and durability under high pressure. Their sturdy design makes them perfect for highly corrosive or demanding environments, promising long-lasting performance with minimal maintenance.
| STANDARD | API 600/BS1414, API 598/BS EN 12266-1, ASME B 16.10, ASME B 16.5, ASME B 16.25, ASME B 16.34 |
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
| SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
| STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
| MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK |
| BRAND NAME | TU-LOK |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| EQUIVALENT BRANDS | SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE |
| APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
|
Tensile Strength (MPa) min |
Yield Strength 0.2% Proof (MPa) min |
Elongation (% in 50mm) min |
Hardness
Rockwell B (HR B) |
Hardness
Brinell (HB) |
|---|---|---|---|---|
|
490 |
220 |
36 |
70-90 typical |
150 |
| C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
|---|---|---|---|---|---|---|---|---|
| 0.02 Max | 2.0 Max | 1.0 Max | 0.045 Max | 0.035 Max | 19.0 Min 23.0 Max | 4.0 Min 5.0 Max | 23.0 Min 28.0 Max | 1.0 Min 2.0 Max |
At Bhavesh Tube Fittings, we are a leading supplier, manufacturer, and exporter of 904l Ball Valve in Houston, USA. Our state-of-the-art manufacturing facilities, strategically located in the USA, enable us to deliver high-quality solutions that meet your specific requirements. With a comprehensive inventory of Monel materials, we are well-equipped to fulfill your needs efficiently. Our commitment to excellence and customer satisfaction ensures that we consistently maintain a ready stock of Monel Manifold Valves to support your operational demands.
Paul Tube Fittings is a leading supplier and stockist of premium 904l Ball Valve in Houston, USA. Our products find extensive application across diverse industries, and we are dedicated to delivering outstanding service while ensuring high customer satisfaction. Our specialized finishing techniques distinguish us in the metal industry, enhancing the performance and durability of our valves. We are committed to consistently providing top-quality Monel Manifold Valves while effectively addressing the unique needs of our customers.
Contact us to get a quick quote for your requirement.
When it comes to uses and applications, 904L ball valves shine in scenarios that demand high corrosion resistance and dependable performance in harsh chemical settings. You’ll find these valves widely utilized in chemical processing plants, marine environments, offshore oil rigs, pharmaceutical facilities, and the pulp and paper industry. Thanks to their exceptional resistance to sulfuric acid, seawater, and chlorides, they’re perfect for managing aggressive fluids and gases. The smooth operation and reliability of these valves make them a go-to choice for many industries.
Please feel free to contact us if you need any further information or for enquiry.
