Butt Weld End Ball Valve

Home > Butt Weld End Ball Valve

Paul Tube Fittings stands out as a top-notch manufacturer and supplier of high-quality Butt Weld End Ball Valves right here in Houston, USA. We take pride in our precision engineering, durability, and performance, ensuring our valves are perfectly suited for the tough demands of industrial applications. With our state-of-the-art manufacturing facilities and a strong commitment to excellence, we provide tailored solutions that guarantee leak-proof connections, hassle-free installation, and a long lifespan. Our Butt Weld End Ball Valves are made from premium materials and rigorously tested to meet international standards, making us a reliable partner for industries such as oil & gas, petrochemicals, power generation, and beyond.

Butt Weld End Ball Valve Supplier in Houston, Socket Weld Valve End Price List in Los Angeles, Butt Weld Valve End Manufacturer in Texas, CF8M Butt Weld End Ball Valve in California, PTFE Butt Weld End Ball Valve Exporter in Los Angeles, Socket Weld End Valve Manufacturer in Houston, CF8M Butt Weld End Ball Valve In Houston, USA.

When it comes to manufacturing Butt Weld End Ball Valves, we typically use stainless steel (SS 304, SS 316), carbon steel, or alloy steel, depending on what the application calls for. These materials are known for their excellent corrosion resistance, high tensile strength, and ability to withstand varying temperatures. The mechanical properties include a tensile strength of up to 515 MPa, yield strength of 205 MPa, and hardness that falls between 70–90 HRB. They ensure reliable sealing and structural integrity even under high pressure and temperature. To boost durability, wear resistance, and longevity in critical process systems, valves are often heat-treated and surface-finished.

Specification of Butt Weld End Ball Valve

Material	CF8M Stainless Steel
Seat	15% glass reinforced RTFE
Component Material	Stem packing: 15% glass reinforced RTFE
Size	½” To 3″
Port	Full
Length	7.3″
Pressure Rating	800 PSI WOG at 65°F (18°C)
Maximum Temperature	400°F (204°C)
Flow	1-Way

Top Butt Weld End Ball Valve Manufacturing Company in Houston

At Paul Tube Fittings, we are the largest supplier, manufacturer, and exporter of Butt Weld End Ball Valve in Houston, USA. Our advanced manufacturing facilities, strategically positioned in the USA, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands

Materials of Butt Weld End Ball Valve

No.	Name	Material	QYT
1	Body	CF8M	1
2	Cap	CF8M	2
3	Ball	CF8M	1
4	Stem	316	1
5	Seat	PTFE+3%.GF	2
6	Thrust.washer	PTFE+15%.Graphite	1
7	Gasket	PTFE+15%.Graphite	2
8	Bolt	304	4
9	Nut	304	4
10	Spring.washer	304	4
11	O.ring	Viton	1
12	Stem.packing	PTFE	1
13	Gland	304	1
14	Butterfly.washer	301	2
15	Lock.wahser	304	1
16	Square.washer	304	1
17	Handle	304	1
18	Flat.ring	304	1
19	Nut	304	2
20	Handle.sleeve	Rubber	1
21	Bolt	304	1
22	Nut	304	1
23	Spring.washer	304	1
24	Locker	304	1

Types of Butt Weld End Ball Valve

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Butt Weld End Ball Valve Supplier in Houston, USA

Paul Tube Fittings is a leading supplier and Stockist of premium Butt Weld End Ball Valve in Houston, USA. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the fittings industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Butt Weld End Ball Valve Uses

Butt Weld End Ball Valves find their place in industries that demand secure and leak-proof flow control systems. You’ll commonly see them in oil & gas pipelines, petrochemical processing, power plants, chemical manufacturing, water treatment systems, and pharmaceutical operations. These valves excel in high-pressure and high-temperature settings, providing full-bore flow with minimal pressure drop. The butt weld end connection guarantees a permanent, tamper-proof seal that’s perfect for handling hazardous and corrosive media. With their sturdy design and low maintenance needs, they are incredibly reliable for both onshore and offshore operations, enhancing system efficiency, safety, and longevity.
