Hastelloy C276 Ball Valve

Home > Hastelloy > Hastelloy C276 Ball Valve

Based in Houston, USA, Paul Tube Fittings is a reliable manufacturer and supplier of high-performance Hastelloy C276 Ball Valves, designed to endure even the toughest chemical and corrosive environments. Crafted from the nickel-molybdenum-chromium alloy Hastelloy C276, these valves boast remarkable resistance to strong oxidizers, reducing agents, acids, and corrosion from chlorides. Engineered for smooth operation and dependable shut-off, Paul Tube Fittings’ Hastelloy ball valves are perfect for chemical processing, pharmaceuticals, marine applications, and pollution control systems. They deliver long-lasting performance under extreme temperatures and pressures, making them the go-to choice for critical applications that demand corrosion resistance and mechanical strength.

Hastelloy Alloy 3 Way C276 Ball Valve in Houston, USA, Hastelloy 4 Way C276 Ball Valve Price in Texas, UNS N10276 Hastelloy 5 Way C276 Ball Valve Supplier in Los Angeles, Hastelloy High Pressure C276 Ball Valve Price List in Houston, Hastelloy Instrumentation C276 Ball Valve Manufacturer in Houston, DIN 2.4819 Hastelloy Alloy Compression C276 Ball Valve in California, Hastelloy Hydraulic C276 Ball Valve Supplier in Los Angeles, Hastelloy High Pressure C276 Ball Valve Price List in Houston, Hastelloy 2 Way C276 Ball Valve Price in California

Hastelloy C276 Ball Valves are crafted from a nickel-based alloy that includes about 57% nickel, 16% molybdenum, 15.5% chromium, 5% iron, along with trace amounts of cobalt and tungsten. This unique blend provides the alloy with outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking in challenging environments. The valves have a tensile strength of around 760 MPa and maintain their mechanical integrity even at high temperatures. Paul Tube Fittings guarantees leak-proof construction, precise sealing, and low-torque operation, making these valves ideal for handling highly corrosive substances like hydrochloric acid, sulfuric acid, and chlorides in demanding industrial settings.

Hastelloy C276 Ball Valve Specifications

STANDARD	ASTM A494 / ASME SA494 API 600/BS1414, ASME B 16.34, ASME B 16.10, ASME B 16.5, API 598/BS EN 12266-1,ASME B 16.25
VALVE SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
THREAD	NPT, BSPP, BSPT, JIC, METRIC, UNF
CONNECTION	THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE
FUNCTION	2 WAY, 3 WAY, 4 WAY, 5 WAY,
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI
SEAL RING MATERIAL	PTFE, PVDF, DELRIN, PEEK, GRAPHITE
STANDARD	ISO , DIN , ANSI , API , ASME , AWWA , MSS ,
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL
MEDIA TEMPERATURE	(-120* C TO 500*C )RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK
PACKING DETAILS	BOX PACKING, WOODEN PALLET
APPLICATION	MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS,

Hastelloy C276 Ball Valve Chemical Composition

Hastelloy C276	Ni	C	Mo	Mn	Si	Fe	P	S	Co	Cr
Hastelloy C276	Balance	0.010 max	15.00 – 17.00	1.00 max	0.08 max	4.00 – 7.00	0.04 max	0.03 max	2.5 max	14.50 – 16.50

Hastelloy C276 Ball Valve Mechanical Properties

Density	Melting Point	Yield Strength (0.2%Offset)	Tensile Strength	Elongation
8.89 g/cm3	1370 °C (2500 °F)	Psi – 52,000 , MPa – 355	Psi – 1,15,000 , MPa – 790	40 %

Hastelloy C276 Ball Valve Equivalent

STANDARD	UNS	WNR Material Number	AFNOR	EN	JIS	BS	GOST
Hastelloy C276	N10276	2.4819	–	NiMo16Cr15W	NW 0276	–	ХН65МВУ

Top Hastelloy C276 Ball Valve Manufacturing Company in Houston

At Paul Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hastelloy C276 Ball Valve in Houston, USA. Our advanced manufacturing facilities, strategically positioned in the USA, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Hastelloy C276 Ball Valve

Hastelloy Alloy 2 Way C276 Ball Valve Supplier in Los Angeles, Hastelloy 3 Way C276 Ball Valve in Houston, USA, Hastelloy Alloy 3 Way C276 Ball Valve Price List in Houston, UNS N10276 Hastelloy 5 Way C276 Ball Valve Price in California, Hastelloy Instrumentation C276 Ball Valve Price in Texas, DIN 2.4819 Hastelloy Compression C276 Ball Valve Supplier in Los Angeles, Hastelloy Hydraulic C276 Ball Valve Manufacturer in Houston, Hastelloy Alloy High Pressure C276 Ball Valve in California

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Hastelloy C276 Ball Valve in Houston, USA

Paul Tube Fittings is a leading supplier and stockist of premium Hastelloy C276 Ball Valve in Houston, USA. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Hastelloy C276 Ball Valve Uses

Hastelloy C276 Ball Valves are specifically engineered for tough service conditions in industries where standard materials just won’t cut it. You’ll find them in chemical reactors, waste treatment facilities, pulp and paper mills, marine exhaust systems, and pharmaceutical manufacturing. These valves excel at managing corrosive fluids, including strong acids, halides, and high-temperature gases. Paul Tube Fittings ensures that their Hastelloy C276 Ball Valves are up to the task, providing reliable performance in the most demanding applications.
