Inconel 625 Ball Valve

Home > Inconel >Inconel 625 Ball Valve

Paul Tube Fittings stands out as a top-notch manufacturer and supplier of high-performance Inconel 625 Ball Valves right here in Houston, USA. We take pride in our dedication to quality, precision engineering, and making our customers happy. Our valves cater to a variety of industries, including chemical processing, marine, and aerospace. The Inconel 625 Ball Valves we offer are designed to withstand extreme temperatures, high pressures, and corrosive environments, making them perfect for tough applications. With a robust supply network and cutting-edge manufacturing capabilities, Paul Tube Fittings provides reliable valve solutions that meet international standards. We guarantee timely delivery, competitive pricing, and technical support tailored to fit your operational needs.

Inconel Instrumentation 625 Ball Valve Manufacturer in Houston, DIN 2.4856 Inconel Alloy Compression 625 Ball Valve in California, Inconel Hydraulic 625 Ball Valve Supplier in Los Angeles, Inconel High Pressure 625 Ball Valve Price List in Houston, Inconel 2 Way 625 Ball Valve Price in California, Inconel Alloy 3 Way 625 Ball Valve in Houston, USA, Inconel 4 Way 625 Ball Valve Price in Texas, Inconel 5 Way 625 Ball UNS N06625 Valve Supplier in Los Angeles, Inconel High Pressure 625 Ball Valve Price List in Houston

Crafted from a nickel-based alloy, our Inconel 625 Ball Valves primarily consist of nickel (at least 58%), along with chromium (20–23%), molybdenum (8–10%), niobium (3.15–4.15%), and iron. This special blend gives them outstanding resistance to oxidation, corrosion, and stress. On the mechanical side, Inconel 625 boasts a tensile strength of about 930 MPa, a yield strength of 517 MPa, and an elongation of roughly 30%. It maintains excellent mechanical stability across a wide temperature range, from cryogenic conditions all the way up to 980°C (1800°F), ensuring durability and reliability even in the most extreme operating conditions.

Inconel 625 Ball Valve Specifications

SPECIFICATION	ASTM A494 / ASME SA494 API 602, ASME B16.34, SME B16.5, ASME B16.25, ASME B1.20.1, ASME B16.11, ASME B16.10, BS 5352, DIN3352
VALVE SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
THREAD	NPT, BSPP, BSPT, JIC, METRIC, UNF
CONNECTION	THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE
FUNCTION	2 WAY, 3 WAY, 4 WAY, 5 WAY,
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI
SEAL RING MATERIAL	PTFE, PVDF, DELRIN, PEEK, GRAPHITE
STANDARD	ISO , DIN , ANSI , API , ASME , AWWA , MSS ,
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL
MEDIA TEMPERATURE	(-120* C TO 500*C )RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK
PACKING DETAILS	BOX PACKING, WOODEN PALLET
APPLICATION	MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS,

Inconel 625 Ball Valve Chemical Composition

Grade		C	Mn	Si	Fe	S	Cr2	Al-Ti	Ni
625	min.	–	–	–	–	–	20.0	–	58.0
625	max.	0.10	0.50	0.50	5.0	0.015	23.0	0.40	–

Inconel 625 Ball Valve Mechanical Properties

Grade	Elongation (% in 50mm) minimum	Strength of Yield 0.2% Proof (MPa) minimum	Strength of Tensile (MPa) minimum	Hardness
				Rockwell B (HR B) maximum	Brinell (HB) maximum
625	42.5	Psi – 75,000 , MPa – 517	Psi – 1,35,000 , MPa -930	–	–

Inconel 625 Ball Valve Equivalent

Grade	UNS No	Old British		Euronorm		GOST	Japanese JIS
		BS	En	No	AFNOR
625	N06625	NA 21	NiCr22Mo9Nb	2.4856	NC22DNB4M	ХН75МБТЮ	NCF 625

Top Inconel 625 Ball Valve Manufacturing Company in Houston

At Paul Tube Fittings, we are the largest supplier, manufacturer, and exporter of Inconel 625 Ball Valve in Houston, USA. Our advanced manufacturing facilities, strategically positioned in the USA, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Inconel 625 Ball Valve

Inconel 3 Way 625 Ball Valve in Houston, USA, DIN 2.4856 Inconel Alloy 3 Way 625 Ball Valve Price List in Houston, Inconel 5 Way 625 Ball Valve Price in California, Inconel Instrumentation 625 Ball Valve Price in Texas, Inconel Compression 625 Ball Valve Supplier in Los Angeles, Inconel Hydraulic 625 Ball Valve Manufacturer in Houston, Inconel Alloy High Pressure 625 Ball Valve in California, UNS N06625 Inconel 2 Way 625 Ball Valve Supplier in Los Angeles

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Inconel 625 Ball Valve in Houston, USA

Paul Tube Fittings is a leading supplier and stockist of premium Inconel 625 Ball Valve in Houston, USA. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Inconel 625 Ball Valve Uses

Inconel 625 Ball Valves are a go-to choice in industries that require strong performance under harsh conditions. These valves shine in chemical processing, offshore oil and gas operations, power generation, and marine engineering, thanks to their resistance to pitting, crevice corrosion, and high-temperature oxidation. They’re commonly used in piping systems to regulate the flow of corrosive fluids, seawater, and high-pressure gases. Aerospace applications also reap the benefits of their impressive strength-to-weight ratio and resistance to thermal fatigue. Paul Tube Fittings provides Inconel 625 Ball Valves specifically designed for these critical sectors, ensuring optimal safety, efficiency, and longevity in challenging operational environments.
