Paul Tube Fittings, located in Houston, USA, stands out as a top manufacturer and supplier of high-quality Inconel Check Valves, specifically designed for efficient flow control in the toughest environments. Crafted from advanced Inconel alloys like Inconel 600, 625, and 825, these valves boast remarkable resistance to extreme temperatures, corrosive substances, and pressure changes. Built to prevent backflow and safeguard essential equipment, Inconel check valves are perfect for demanding industrial settings. Paul Tube Fittings guarantees precision engineering, leak-proof seals, and a long lifespan—making these valves the go-to choice for sectors such as aerospace, chemical processing, marine, and oil & gas.
The Inconel Check Valves from Paul Tube Fittings are made from nickel-chromium-based alloys, including Inconel 600, 625, and 825. These materials showcase impressive mechanical properties, such as high tensile strength (550–850 MPa), excellent fatigue resistance, and remarkable thermal stability. Inconel is known for its resistance to oxidation, pitting, and chloride stress corrosion cracking, making it ideal for harsh and high-temperature environments. The valves are designed for precision and durability, ensuring consistent, leak-free performance even under severe mechanical and thermal conditions—making them a trustworthy choice for critical flow control needs.
| CONNECTION | SOCKET WELD END, TUBE END, THREADED, FLANGE END |
| INSTRUMENTATION VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| THREADS | BSPP, NPT, METRIC, BSPT,UNF, JIC |
| INSTRUMENTATION VALVES BODY SHAPE | HEXAGON |
| PATTERN FLOW | STRAIGHT |
| INSTRUMENTATION VALVES ORIFICE SIZE | 2 MM – 40 MM |
| EQUIVALENT BRANDS | PARKER, SWAGELOK, DK-LOK, STAUFF, OLIVER VALVES, HAMLET, HOKE |
| RATING PRESSURE | 20000 PSI, 1500 PSI, 10000 PSI, 3000 PSI, 6000 PSI, 15,000 PSI |
| CRACKING PRESSURE | 0.5 BAR |
| TYPE | SPRING TYPE, POPPET TYPE |
| INSTRUMENTATION VALVES MATERIAL | INCONEL |
| MEDIA | SEA WATER , HYDRAULIC AIR, OIL, GAS, WATER, HOT WATER , STEAM, COLD WATER , CHEMICAL |
| BODY TYPE | FORGED, BAR STOCK |
| MEDIA TEMPERATURE | (-50* C – 350*C ) AS PER PRESSURE RANGE |
| INSTRUMENTATION VALVES PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Inconel | Element (% By Mass) | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Mo | Ni | Cr | Fe | Mn | Nb | Co | Cu | Al | Ti | Si | C | B | S | P | |
| 690 | 59.05 | 30 | 9.02 | 0.035 | 0.001 | 0.002 | 0.035 | 0.0019 | 0.0003 | ||||||
| 617 | 8.00 to 10.00 | 44.02 to 56.00 | 20.00 to 24.00 | 3.00 | 0.05 | 10.00 to 15.00 | 0.05 | 0.08 to 1.05 | 0.06 | 0.05 | 0.015 | 0.0006 | 0.0015 | 0.0015 | |
| 600 | 72.00 | 14.00 to 17.00 | 6.00 to 10.00 | 1.00 | 0.05 | 0.05 | 0.015 | 0.0015 | |||||||
| 625 | 8.00 to 10.00 | 58.00 | 20.00 to 23.00 | 5.00 | 0.05 | 3.015 to 4.015 | 1.00 | 0.04 | 0.04 | 0.05 | 0.01 | 0.0015 | 0.0015 | ||
| X-750 | 70.00 | 14.00 to 17.00 | 5.00 to 9.00 | 1.00 | 0.07 to 1.02 | 1.00 | 0.05 | 0.04 to 1.00 | 2.025 to 2.075 | 0.05 | 0.008 | 0.001 | |||
| 718 | 2.08 to 3.03 | 50.00 to 55.00 | 17.00 to 21.00 | Balance | 0.035 | 4.075 to 5.05 | 1.00 | 0.02 to 0.08 | 0.065 to 1.015 | 0.03 | 0.035 | 0.008 | 0.0006 | 0.0015 | 0.0015 |
| Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | |||
| Psi – 1,35,000 , MPa -930 | 42.5 | Psi – 75,000 , MPa – 517 | – | – |
At Paul Tube Fittings, we are the leading supplier, manufacturer, and exporter of Inconel Check Valves in Houston, USA. Our advanced manufacturing facilities, strategically located in the USA, enable us to provide high-quality, customized solutions tailored to your specific needs. With an extensive inventory of over 16,000 tons of premium-grade Inconel materials, we are well-equipped to meet your demands efficiently. Our commitment to excellence and efficiency ensures that we consistently maintain sufficient stock to support your business requirements and deliver superior performance in critical applications.
| Standard | Inconel 600 | Inconel 601 | Inconel 625 | Inconel 718 |
|---|---|---|---|---|
| UNS | N06600 | N06601 | N06625 | N07718 |
| EN | NiCr15Fe | NiCr23Fe | NiCr22Mo9Nb | – |
| BS | NA 13 | NA 49 | NA 21 | – |
| GOST | МНЖМц 28-2,5-1,5 | XH60BT | ХН75МБТЮ | – |
| WERKSTOFF NR. | 2.4816 | 2.4851 | 2.4856 | 2.4668 |
| OR | ЭИ868 | ЭИ868 | ЭИ602 | – |
| JIS | NCF 600 | NCF 601 | NCF 625 | – |
| AFNOR | NC15FE11M | NC23FeA | NC22DNB4M | – |
Paul Tube Fittings is a leading supplier and stockist of premium Inconel Check Valves in Houston, USA. Our products are widely utilized across various industries, and we are dedicated to delivering exceptional service while ensuring complete customer satisfaction. With our advanced finishing techniques, we stand out in the metal industry. We are committed to consistently providing top-quality Inconel Check Valves while efficiently meeting the diverse needs of our clients, ensuring reliability and performance in demanding applications.
Contact us to get a quick quote for your requirement.
Inconel Check Valves play a vital role in situations where preventing backflow is crucial, especially in extreme conditions. These valves find extensive use in power generation, offshore oil rigs, nuclear plants, aerospace systems, chemical processing, and high-pressure steam lines. Their sturdy design and exceptional corrosion resistance enable them to manage aggressive substances like acids, seawater, and high-temperature gases. Paul Tube Fittings’ Inconel Check Valves guarantee unidirectional flow, protect pumps and instruments, and boost system safety and efficiency. Their durability and high integrity make them an essential component in critical flow control applications.
Please feel free to contact us if you need any further information or for enquiry.
