Hastelloy Condensate Pots

Home > Hastelloy > Hastelloy Condensate Pots

Paul Tube Fittings, based in Houston, USA, stands out as a top-notch manufacturer and supplier of high-quality Hastelloy Condensate Pots. These pots are expertly designed to provide precise pressure measurements in harsh, corrosive environments. Made from advanced Hastelloy alloys like C22 or C276, they effectively collect and isolate condensate from gases and steam before it reaches sensitive instruments. With exceptional corrosion resistance, thermal stability, and mechanical strength, Paul Tube Fittings’ Hastelloy Condensate Pots are perfect for demanding industrial applications. Each unit is meticulously crafted to meet international standards, ensuring reliability, safety, and a long lifespan in the chemical, oil & gas, and marine industries.

C22 Hastelloy Type A Condensate Pot Manufacturer Houston, UNS N06022 Type B Condensate Pots Manifolds Dealer Los Angeles, Hastelloy Type C Condensate Pot with Red Oxide Coated Supplier Texas, Hastelloy Type A Condensate Pot with Galvanized Plating Exporter In California, Hastelloy® Alloy Type B Condensate Pot with Zinc Plating Dealer In Houston, Hastelloy Condensate Pot Type C Supplier In Houston, USA.

The Hastelloy Condensate Pots from Paul Tube Fittings are made from Hastelloy C22 or C276, which are cutting-edge nickel-chromium-molybdenum alloys celebrated for their remarkable resistance to corrosion. These materials can withstand oxidizing and reducing agents, acids, chlorides, and pitting, making them perfect for extreme conditions. With tensile strengths reaching up to 690 MPa and impressive resistance to creep and stress rupture, these pots maintain their structural integrity even under high temperatures and pressures. Built to endure thermal cycling and chemical attacks, the Hastelloy construction guarantees reliable performance and a long service life. Each condensate pot is carefully machined and tested to ensure durability in tough process environments.

Hastelloy Instrumentation Manifolds Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Sizing Of Hastelloy Condensing Pot

P NPT – F	Capacity (Internal Vol.0)cm 3±5%	Pressure Rating PSIG	T mm	L mm	B mm
1/4”	150	1800	2.05	135	50.08
1/4”	300	1800	2.05	225	50.08
1/4”	400	1800	2.05	290	50.08
1/4”	500	1800	2.05	350	50.08
1/4”	1000	1800	4.06	275	88.09
1/4”	2250	1800	5.02	435	120
1/4”	3785	1800	5.02	680	120
1/2”	1000	1800	4.06	275	88.09
1/2”	2250	1800	5.02	435	102
1/2”	3785	1800	5.02	680	102
3/4”	1000	1800	4.06	275	88.09
3/4”	2250	1800	5.02	435	102
3/4”	3785	1800	5.02	680	102

Top Hastelloy Instrumentation Manifolds Manufacturing Company in Houston

At Paul Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hastelloy Instrumentation Manifolds in Houston, USA. Our advanced manufacturing facilities, strategically positioned in the USA, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Hastelloy Instrumentation Manifolds

Hastelloy® Alloy Type A Condensate Pot with Red Oxide Coated Price in Houston, Hastelloy Type B Condensate Pot with Galvanized Plating Manufacturer Supplier in Los Angeles, Hastelloy Type A Condensate Pots with 2 Ports Manufacturer in Texas, Hastelloy Condensate Pot Type B Supplier Price in California, Hastelloy Type C Condensate Pots with 4 Ports Supplier And Manufacturer in Houston, Alloy C276 Type A Condensate Pots In Houston, USA.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Hastelloy Instrumentation Manifolds Supplier in Houston, USA

Paul Tube Fittings is a leading supplier and stockist of premium Hastelloy Instrumentation Manifolds in Houston, USA. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Hastelloy Instrumentation Manifolds Uses

Hastelloy Condensate Pots are crucial in pressure measurement and instrumentation systems where accurate readings and protection of equipment are vital in corrosive conditions. These pots find their place in power plants, offshore platforms, chemical refineries, and pharmaceutical production facilities. They effectively collect condensate or debris from steam or gas lines, preventing contamination or damage to pressure instruments. Paul Tube Fittings’ Hastelloy Condensate Pots are designed to ensure optimal performance and longevity in these challenging applications.
