Paul Tube Fittings stands out as a top-notch manufacturer and supplier of high-quality Hydraulic Equal Cross fittings right here in Houston, USA. We’ve built a reputation for our commitment to quality, precision, and durability, ensuring that our fittings are crafted to meet the highest industry standards. With a diverse selection of sizes and specifications, we cater to a variety of hydraulic applications. Our focus on innovation and customer satisfaction means that Paul Tube Fittings delivers solutions designed for leak-free, reliable performance, even in the toughest environments. Being based in Houston allows us to respond quickly and efficiently to our clients across different industries, making us a trusted partner for all your hydraulic fitting needs.
When it comes to materials, our Hydraulic Equal Cross fittings are typically made from stainless steel (SS 316/304), carbon steel, brass, and alloy steel, all chosen for their corrosion resistance and strength. They boast impressive mechanical properties, including high tensile strength (up to 515 MPa), good elongation (20%+), and strong yield strength (around 205 MPa for SS 304). To enhance their durability and pressure resistance, these fittings undergo heat treatment, ensuring they have a long service life. They maintain their structural integrity even under high pressure and temperature, making them perfect for demanding hydraulic systems and fluid transfer operations.
| STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | MS, CS, SS 304 ,SS 304L , SS 316 ,SS 316L, SS 316TI ( 1.4571) , BRASS , COPPER , DUPLEX , SUPER DUPLEX , INCONEL , MONEL , HASTELLOY , 904L , 6MO, TITANIUM , ALUMNIUM, ALLOY 20 |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | CARBON STEEL -TRIVALENT ZINC PLATED , YELLOW PLATTING , BLACK PHOSPHATED, |
| STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH | |
| TEMPERATURE | STEEL – (-40* C TO 120*C) ,STAINLESS STEEL – (-60*C TO 400*C) BRASS – (-60*C TO 175*C) |
| EQUIVALENT BRANDS | PARKER, HY-LOK , DK-LOK , STAUFF, HYDAC , VOSS |
| APPLICATIONS & INDUSTRIES | CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT |
At Paul Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hydraulic Equal Cross in Houston, USA. Our advanced manufacturing facilities, strategically positioned in the USA, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.
| Thread | CH | L1 | L2 | T1 | Pressure PN | Weight kg 100pcs | Series |
|---|---|---|---|---|---|---|---|
| Thread F1 | mm | mm | mm | mm | bar | ||
| 12×1,5 | 12 | 12 | 27 | 6 | 315 | 7,8 | L |
| 12×1,5 | 12 | 12 | 27 | 6 | 315 | 7,8 | L |
| 14×1,5 | 12 | 14 | 29 | 8 | 315 | 11,0 | L |
| 14×1,5 | 12 | 14 | 29 | 8 | 315 | 11,0 | L |
| 16×1,5 | 14 | 15 | 30 | 10 | 315 | 15,7 | L |
| 16×1,5 | 14 | 15 | 30 | 10 | 315 | 15,7 | L |
| 18×1,5 | 17 | 17 | 32 | 12 | 315 | 19,5 | L |
| 18×1,5 | 17 | 17 | 32 | 12 | 315 | 19,5 | L |
| 22×1,5 | 19 | 21 | 36 | 15 | 315 | 31,5 | L |
| 22×1,5 | 19 | 21 | 36 | 15 | 315 | 31,5 | L |
| 26×1,5 | 24 | 23,5 | 40 | 18 | 315 | 48,7 | L |
| 26×1,5 | 24 | 23,5 | 40 | 18 | 315 | 48,7 | L |
| 30×2 | 27 | 27,5 | 44 | 22 | 160 | 73,0 | L |
| 30×2 | 27 | 27,5 | 44 | 22 | 160 | 73,0 | L |
| 36×2 | 36 | 30,5 | 47 | 28 | 160 | 101,5 | L |
| 36×2 | 36 | 30,5 | 47 | 28 | 160 | 101,5 | L |
| 45×2 | 41 | 34,5 | 56 | 35 | 160 | 123,5 | L |
| 45×2 | 41 | 34,5 | 56 | 35 | 160 | 123,5 | L |
| 52×2 | 50 | 40 | 63 | 42 | 160 | 176,5 | L |
| 52×2 | 50 | 40 | 63 | 42 | 160 | 176,5 | L |
| 14×1,5 | 12 | 16 | 31 | 6 | 630 | 13,0 | S |
| 14×1,5 | 12 | 16 | 31 | 6 | 630 | 13,0 | S |
| 16×1,5 | 14 | 17 | 32 | 8 | 630 | 17,0 | S |
| 16×1,5 | 14 | 17 | 32 | 8 | 630 | 17,0 | S |
| 18×1,5 | 17 | 17,5 | 34 | 10 | 630 | 24,2 | S |
| 18×1,5 | 17 | 17,5 | 34 | 10 | 630 | 24,2 | S |
| 20×1,5 | 17 | 21,5 | 38 | 12 | 630 | 30,1 | S |
| 20×1,5 | 17 | 21,5 | 38 | 12 | 630 | 30,1 | S |
| 22×1,5 | 19 | 22 | 40 | 14 | 630 | 39,0 | S |
| 22×1,5 | 19 | 22 | 40 | 14 | 630 | 39,0 | S |
| 24×1,5 | 24 | 24,5 | 43 | 16 | 400 | 49,0 | S |
| 24×1,5 | 24 | 24,5 | 43 | 16 | 400 | 49,0 | S |
| 30×2 | 27 | 26,5 | 48 | 20 | 400 | 76,0 | S |
| 30×2 | 27 | 26,5 | 48 | 20 | 400 | 76,0 | S |
| 36×2 | 36 | 30 | 54 | 25 | 400 | 138,0 | S |
| 36×2 | 36 | 30 | 54 | 25 | 400 | 138,0 | S |
| 42×2 | 41 | 35,5 | 62 | 30 | 400 | 172,0 | S |
| 42×2 | 41 | 35,5 | 62 | 30 | 400 | 172,0 | S |
| 52×2 | 50 | 41 | 72 | 38 | 315 | 269,0 | S |
| 52×2 | 50 | 41 | 72 | 38 | 315 | 269,0 | S |
Contact us to get a quick quote for your requirement.
Paul Tube Fittings is a leading supplier and stockist of premium Hydraulic Equal Cross in Houston, USA. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.
Hydraulic Equal Cross fittings play a crucial role in fluid power systems where four equal-sized pipes or tubes need to connect seamlessly. They’re widely utilized in hydraulic and pneumatic applications for distributing fluids in multiple directions. Industries such as automotive, aerospace, oil and gas, marine, construction, and manufacturing rely on these fittings. They help create efficient branching networks within complex hydraulic circuits, ensuring smooth and controlled flow. With their robust design, they can handle high-pressure environments, making them ideal for heavy-duty equipment, hydraulic presses, and other high-performance machinery that requires reliable, leak-proof connections.
