Hydraulic Sae Flange Ball Valve

Home > Hydraulic Sae Flange Ball Valve

Paul Tube Fittings stands out as a top-notch manufacturer and supplier of Hydraulic SAE Flange Ball Valves, proudly based in Houston, USA. Known for their high-performance fluid control solutions, they offer valves that are not only durable but also reliable, built to handle high pressures and tough industrial environments. With a strong emphasis on quality, precision, and customer satisfaction, Paul Tube Fittings provides a diverse range of hydraulic components designed to meet the needs of various industries, including oil & gas, petrochemical, marine, and construction. Their SAE flange ball valves are crafted using cutting-edge technology, guaranteeing leak-free performance and a long lifespan, even in the most extreme conditions.

Hydraulic Sae Flange Ball Valve Supplier in Houston, SAE Flanged End Ball Valve Price List in Los Angeles, SS316 Ball Valves Manufacturer in Texas, Hexagon shape Hydraulic Sae Flange Ball Valve in California, Hydraulic Sae Threaded Ball Valve Exporter in Los Angeles, Hydraulic Sae Compression Ball Valve Manufacturer in Houston, Hydraulic Sae Flange Ball Valve In Houston, USA.

Typically, Hydraulic SAE Flange Ball Valves are made from high-grade stainless steel (like SS 316), carbon steel, or other alloyed steels, which provide excellent corrosion resistance and structural integrity. These valves boast impressive tensile strength (up to 600 MPa), good elongation (over 15%), and outstanding impact resistance. The ball within the valve is precision-machined and chrome-plated, ensuring smooth operation and durability. Seals are often crafted from PTFE or Viton, which guarantees chemical compatibility and leak resistance. Designed to handle pressures up to 6000 PSI, these valves are perfect for demanding hydraulic systems.

KhpHydraulic Sae Flange Ball Valve Specification

Size Range: 1/8″ TO 2″ / 6 MM TO 50 MM
Design: Quarter Turn Type
Material: Steel / SS316
Working Pressure: 3000 PSI / 6000 PSI
Connections: SAE Flanged End, Code 61 / Code 62
Brand: TU-LOK
Applicable Medium: General Hydraulic Oil (Gas Application on request)
Temperature Range for Steel Ball Valves: -20°C to +100°C
Temperature Range for SS316 Ball Valves: -30°C to +100°C
Ball Seats: POM (POM standard option, other materials on request)
Stem and Adaptor Sealing Materials: NBR (NBR standard option, other materials on request)

Top Hydraulic Sae Flange Ball Valve Manufacturing Company in Houston

At Paul Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hydraulic Sae Flange Ball Valve in Houston, USA. Our advanced manufacturing facilities, strategically positioned in the USA, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands

types of ball valves

Valve Type	BKH / BKHP	MKH / MKHP	KH
Diameter Size	1/8″ to 1″	1 1/4” to 2	1/2” to 3”
Working Pressure	Up to 800 Bar	Up to 420 Bar	Up to 420 Bar
Body Design	Square shape	Round / Hexagon shape	Round shape
Connection Type	Threaded Compression Flange end	Threaded Compression Flange end	Flange end

Types of Hydraulic Sae Flange Ball Valve

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Hydraulic Sae Ball Valve Supplier In Texas, SAE Flanged End Ball Valve Exporter In Houston, SS316 Ball Valves Dealer In Los Angeles, Hydraulic Sae Hexagon shape Ball Valve Supplier in Houston, Hydraulic Sae Threaded Ball Valve Price List in Los Angeles, Hydraulic Sae Compression Ball Valve Manufacturer in Texas, Hydraulic Sae Flange end Ball Valve in California, Hydraulic Sae Ball Valve Exporter in Los Angeles, Hydraulic SAE Flanged End Ball Valve Manufacturer in Houston, Hydraulic Sae Flange Ball Valve In Houston, USA.

Ball valve with SAE flange flow rate

Nominal Diameter (mm)	Nominal Diameter (inch)	Kv (m3/h)	Cv (gal/min)
15	1/2″	19,4	22,6
20	3/4″	45,6	53,0
25	1″	71,5	83,1
32	1 1/4″	105	122,1
40	1 1/2″	170	197,7
50	2″	275	319,8
65	2 1/2″	507	589,5
80	3″	905	1052,3
100	4″	1414	1644,2
125	5″	2362	2746,5
150	6″	3694	4295,3

Hydraulic Sae Flange Ball Valve Supplier in Houston, USA

Paul Tube Fittings is a leading supplier and Stockist of premium Hydraulic Sae Flange Ball Valve in Houston, USA. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the fittings industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Hydraulic Sae Flange Ball Valve Uses

You’ll find Hydraulic SAE Flange Ball Valves widely used across various industrial sectors, thanks to their sturdy design and efficient shut-off capabilities. In hydraulic systems, they play a crucial role in regulating fluid flow and isolating components for maintenance. Common applications include heavy machinery, mobile equipment, offshore drilling rigs, power generation, and shipbuilding. These valves are vital in systems where high pressure and fluid cleanliness are paramount. The SAE flange connection allows for easy installation and a secure, leak-proof fit, making them ideal for high-pressure hydraulic circuits. Their reliability and durability make them the go-to choice for mission-critical operations in extreme environments.
