Male Connector

Home > Male Connector

Paul Tube Fittings stands out as a top manufacturer and supplier of Male Connectors right in Houston, USA. They provide high-precision solutions for dependable tube-to-thread connections across various fluid and gas systems. Designed for strength, durability, and leak-proof performance, these fittings make it easy and secure to connect tubing to female-threaded ports. Paul Tube Fittings offers male connectors in a range of sizes and thread types (NPT, BSP, ISO, UNF), crafted from premium materials and cutting-edge machining techniques. Their products adhere to international standards and are trusted in industries like oil & gas, chemical, instrumentation, and power generation for their consistent, corrosion-resistant, and high-pressure performance.

Npt Male Adapter In Houston, Bsp Female To Npt Male Adapter Exporter In California, Metric Male To Npt Male Adapter Dealer In Los Angeles, 1 Inch Npt Male Connector and Metric Male To Npt Male Adapter are machined from close grain forgings In Texas, EC79 certified 316 Stainless Steel Npt Female Connector and Brass BSP Connector manufacturers in Houston, USA.

Male Connectors are typically made from sturdy materials such as stainless steel (SS 316/304), carbon steel, brass, and high-performance alloys like Monel, Inconel, and Hastelloy. These materials provide outstanding mechanical strength, resistance to corrosion, and the ability to handle high pressure. With precision-machined threads and ferrule systems, these connectors ensure leak-proof connections even under vibration and temperature changes. Their mechanical properties include tensile strength reaching up to 100 ksi, impressive hardness, and excellent resistance to fatigue and pressure. Paul Tube Fittings guarantees that all connectors are produced with tight tolerances to ensure reliable performance in critical process and instrumentation systems.

Male Connector Specifications

One Side: MM OD Tube
Other Side: NPT Thread
Material: carbon steel, SS 304, 304L, 316, 316L ,brass and etc.
Tube OD Size: 3 to 25 mm
Thread size: 1/8″ to 2″inch.
Thread standard : NPT
Applicable medium: oil, water,gas and other medium.
Specified Specification : available upon request.
Features: safe, reliable and leak-proof connection easy installation

Bsp Female To Npt Male Adapter Metric Sizes

MALE CONNECTOR NPT – METRIC
BSPP thread	Tube O.D	R	C	A	D	X	W	Min bore
BSPP thread	mm	mm	mm	mm	mm	mm	inch	mm
1/4	6	11.2	17.7	37.7	30.2	17.8	3/4	4.8
1/8	6	7.1	17.7	32.5	25.0	13.7	9/16	4.0
1/4	8	11.2	18.6	38.5	31.0	17.8	3/4	6.4
1/2	6	14.2	17.7	44.8	37.3	25.7	1.1/16	4.8
3/8	8	11.2	18.6	39.3	31.8	21.8	7/8	6.4
1/4	10	11.2	19.5	39.4	31.8	17.8	3/4	6.4
1/2	8	14.2	18.6	44.0	36.5	25.7	1.1/16	6.4
3/8	10	11.2	19.5	40.5	32.9	21.8	7/8	7.9
1/4	12	11.2	22.0	42.6	32.5	17.8	13/16	6.4
1/2	10	14.2	19.5	46.5	38.9	25.7	1.1/16	7.9
3/8	12		22.0	43.4	33.3

Top Male Connector Manufacturing Company in Houston

At Paul Tube Fittings, we are the largest supplier, manufacturer, and exporter of Male Connector in Houston, USA. Our advanced manufacturing facilities, strategically positioned in the USA, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Male Connector

Brass Male To Male Adapter Price In Houston, Stainless Steel Male Connector NPT Exporter In Texas, SS 304 Mnpt Connector In Los Angeles, 316 Stainless Steel Bspt Connector In California, Male Connector NPT In Houston, 1 Inch Npt Female Connector Manufacturer In Houston, USA.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Male Connector in Houston, USA

Paul Tube Fittings is a leading supplier and Stockist of premium Male Connector in Houston, USA. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Male Connector Uses

Male Connectors find extensive use in fluid and gas transfer systems, connecting tubing to female-threaded components or ports. They play a crucial role in sectors like oil & gas, chemical processing, power generation, hydraulic systems, pharmaceutical manufacturing, and instrumentation setups. These fittings provide strong, vibration-resistant, and leak-free connections, even in demanding environments.
