Stainless Steel 304 Ball Valve

Home > Stainless Steel > Stainless Steel 304 Ball Valve

Based in Houston, USA, Paul Tube Fittings stands out as a top manufacturer and supplier of high-quality Stainless Steel 304 Ball Valves. The company is renowned for its commitment to excellence and engineering precision, delivering durable and cost-effective valve solutions for a variety of fluid control needs. These SS 304 ball valves are crafted to ensure reliable shut-off performance, resist corrosion, and simplify maintenance. With a solid foothold in sectors like water treatment, food processing, HVAC, and general engineering, Paul Tube Fittings guarantees that its valves adhere to strict quality and safety standards, making them a trusted option for both industrial and commercial applications.

Stainless Steel 304 Instrumentation Ball Valve Manufacturer in Houston, Stainless Steel DIN 1.4301 Compression Ball Valve in California, SS UNS S30400 Hydraulic Ball Valve Supplier in Los Angeles, X5CrNi18-10 Stainless Steel High Pressure Ball Valve Price List in Houston, 304 Stainless Steel 2 Way Ball Valve Price in California, DIN 1.4301 SS 3 Way Ball Valve in Houston, USA, UNS S30400 Stainless Steel 4 Way Ball Valve Price in Texas, 304 Stainless Steel 5 Way Ball Valve Supplier in Los Angeles

Stainless Steel 304 Ball Valves are primarily composed of iron, featuring 18–20% chromium and 8–10.5% nickel, which provides outstanding general corrosion resistance along with solid mechanical properties. With a tensile strength of about 515 MPa (75,000 psi) and a yield strength of 205 MPa (30,000 psi), SS 304 performs well under moderate temperature and pressure conditions. It boasts good elongation and toughness, making it perfect for forming and welding tasks. While it may not resist chlorides as effectively as 316, SS 304 remains a cost-effective and durable choice for many non-aggressive fluid control systems.

Stainless Steel 304 Ball Valve Specifications

VALVE SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
THREAD	NPT, BSPP, BSPT, JIC, METRIC, UNF
CONNECTION	THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE
FUNCTION	2 WAY, 3 WAY, 4 WAY, 5 WAY,
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI
SEAL RING MATERIAL	PTFE, PVDF, DELRIN, PEEK, GRAPHITE
STANDARD	ISO , DIN , ANSI , API , ASME , AWWA , MSS ,
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL
MEDIA TEMPERATURE	(-120* C TO 500*C )RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK
PACKING DETAILS	BOX PACKING, WOODEN PALLET
APPLICATION	MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS,

Stainless Steel 304 Ball Valve Chemical Composition

Grade		Mn	C	Si	S	Cr	P	N	Mo
304	minimum maximum	– 2.0	– 0.08	– 0.75	– 0.030	18.0 20.0	– 0.045	– 0.10	–
304L	minimum maximum	– 2.0	– 0.030	– 0.75	– 0.030	18.0 20.0	– 0.045	– 0.10	–
304H	minimum maximum	– 2.0	0.04 0.10	– 0.75	– 0.030	18.0 20.0	-0.045	–	–

Stainless Steel 304 Ball Valve Mechanical Properties

Grade	(% in 50mm) Elongation minimum	0.2% Proof Yield Strength (MPa) minimum	Strength of Tensile (MPa) minimum	Hardness
Grade	(% in 50mm) Elongation minimum	0.2% Proof Yield Strength (MPa) minimum	Strength of Tensile (MPa) minimum	Brinell (HB) max	Rockwell B (HR B) max
304	40	205	515	201	92
304L	40	170	485	201	92
304H	40	205	515	201	92

Stainless Steel 304 Ball Valve Equivalent

Grade	British		Euronorm		UNS No.	SS	JIS
Grade	European Standards	British Standards	Name	DIN No.	UNS No.	SS	JIS
304	58E	304S31	X5CrNi18-10	1.4301	S30400	2332	SUS 304
304L	–	304S11	X2CrNi19-11	1.4306	S30403	2352	SUS 304L
304H	–	304S51	X6CrNi18-11	1.4948	S30409	–	–

Top Stainless Steel 304 Ball Valve Manufacturing Company in Houston

At Paul Tube Fittings, we are the largest supplier, manufacturer, and exporter of Stainless Steel 304 Ball Valve in Houston, USA. Our advanced manufacturing facilities, strategically positioned in the USA, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Stainless Steel 304 Ball Valve

Stainless Steel 304 Instrumentation Ball Valve Price in Texas, UNS S30400 Stainless Steel Compression Ball Valve Supplier in Los Angeles, X5CrNi18-10 Stainless Steel Hydraulic Ball Valve Manufacturer in Houston, DIN 1.4301 Stainless Steel High Pressure Ball Valve in California, 304 Stainless Steel 2 Way Ball Valve Supplier in Los Angeles, UNS S30400 Stainless Steel 3 Way Ball Valve in Houston, USA, DIN 1.4301 Stainless Steel 3 Way Ball Valve Price List in Houston, 304 SS 5 Way Ball Valve Price in California

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Stainless Steel 304 Ball Valve in Houston, USA

Paul Tube Fittings is a leading supplier and stockist of premium Stainless Steel 304 Ball Valve in Houston, USA. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Stainless Steel 304 Ball Valves Uses

Stainless Steel 304 Ball Valves find extensive use in scenarios where corrosion resistance, hygiene, and cost-effectiveness are key. Common industries include food and beverage, water supply, pharmaceuticals, HVAC systems, and light chemical processing. These valves are perfect for general flow control and are celebrated for their user-friendly operation and long lifespan. Paul Tube Fittings’ SS 304 ball valves are particularly suited for non-corrosive and mildly corrosive environments, providing dependable shut-off and requiring minimal maintenance. Their clean finish and compatibility with various systems make them a reliable choice for many applications.
