Paul Tube Fittings is a premier manufacturer and supplier of Stainless Steel 316Ti Ball Valves in Houston, USA. With a reputation for quality, innovation, and precision engineering, Paul Tube Fittings supplies high-quality valves that meet international standards in various sectors. With the Stainless Steel 316Ti Ball Valve, one can expect great corrosion resistance, high-temperature strength, and long-term durability, which makes it a perfect choice for demanding applications. Backed by a robust distribution network and customer-centric service, Paul Tube Fittings provides timely delivery and technical assistance for the various requirements of the petrochemical, pharmaceutical, and oil & gas industries.
Stainless Steel 316Ti is a titanium-stabilized grade of 316 stainless steel with improved resistance against intergranular corrosion. Its composition is typically 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and with minor additions of titanium (0.5%). This alloy has superior mechanical strength with tensile strength of approximately 515 MPa, yield strength of 205 MPa, and elongation of 35%. It has stability at high temperatures and shows superior creep resistance and is ideal for valve applications under high pressure and high temperature such as the 316Ti Ball Valve.
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
| SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
| STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
| MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK |
| BRAND NAME | TU-LOK |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| EQUIVALENT BRANDS | SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE |
| APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
Grade | C | Ni | Si | N | S | Mn | P | Cr | Mo | |
SS 316Ti | min. | – | 10.0 | – | – | – | – | – | 16.0 | 2.00 |
max. | 0.08 | 14.0 | 0.75 | 0.10 | 0.030 | 2.0 | 0.045 | 18.0 | 3.00 | |
Grade | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness |
Rockwell B (HR B) max | ||||
SS 316Ti | 515 | 35 | 205 | 75 |
STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
SS 316Ti | S31635 | 1.4571 | Z6CNDT17‐12 | X6CrNiMoTi17-12-2 | SUS 316Ti | 320S31 | 08Ch17N13M2T |
Contact us to get a quick quote for your requirement.
Stainless Steel 316Ti Ball Valves are popularly applied in process industries requiring superior corrosion resistance and high-temperature applications. Typical uses cover chemical processing, pharmaceutical production, marine and offshore equipment, food and beverage processing, and oil & gas refineries. Their durable design enables them to accommodate aggressive fluids and unfavorable environments without degrading. The titanium stabilization is effective in avoiding carbide precipitation, providing long-term reliability even in high temperatures. These valves are also utilized in heat exchangers, power generation, and water treatment plants where reliable flow regulation and scaling or pitting resistance are essential to system operation.
Please feel free to contact us if you need any further information or for enquiry.
