Paul Tube Fittings is a reputable Houston, USA-based manufacturer and supplier of high-performance Super Duplex Stainless Steel Condensate Pots. We are dedicated to precision engineering and higher quality, supporting a wide range of industries including petrochemical, oil & gas, and power generation. Our condensate pots are specifically designed to maintain system reliability by avoiding direct contact between instrumentation and condensate. Supported by decades of experience, advanced manufacturing facilities, and rigorous quality control, Paul Tube Fittings provides bespoke solutions addressing the most stringent industrial requirements and international standards.

S32750 Super Duplex Stainless Steel Condensate Pots Type A Manufacturer Houston, Super Duplex Stainless Steel Type B Condensate Pot with Red Oxide Coated Dealer Los Angeles, Super Duplex Stainless Steel Condensate Pot Type C Supplier In Texas, S32760 Super Duplex Stainless Steel Type A Condensate Pot Exporter In California, Super Duplex Stainless Steel Type B Condensate Pots with 3 Ports Manufacturer Houston, Super Duplex Stainless Steel Condensate Pot Type B Supplier Houston, USA.

Super Duplex Stainless Steel Condensate Pots consist mainly of chromium (24–26%), nickel (6–8%), molybdenum (3–5%), and nitrogen (0.2–0.3%), with iron and trace elements. The composition is highly resistant to corrosion, particularly chloride-induced stress corrosion cracking. The alloy has high tensile strength (~750 MPa), yield strength (~550 MPa), and superb impact resistance at sub-zero temperatures too. Its microstructure is dual-phase, which makes it highly durable, weldable, and resistant to fatigue. All these characteristics make it the preferred alloy for high-pressure and corrosive service applications where strength and dependability are essential.

Super Duplex Stainless Steel Condensate Pots Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Super Duplex Stainless Steel Condensate Pots Chemical Properties

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	N	Fe
S32750	0.030 max	1.20 max	0.80 max	0.035 max	0.020 max	24.00 – 26.00	3.00 – 5.00	6.00 – 8.00	0.24 – 0.32	58.095 min
S32760	0.05 max	1.00 max	1.00 max	0.030 max	0.010 max	24.00 – 26.00	3.00 – 4.00	6.00 – 8.00	0.20 – 0.30	57.61 min

Equivalent of Super Duplex Stainless Steel Condensate Pots

STANDARD	WERKSTOFF NR.	UNS
Super Duplex 2507	1.4410	S32750 / S32760

Top Super Duplex Stainless Steel Condensate Pots Manufacturing Company in Houston

At Paul Tube Fittings, we are the largest supplier, manufacturer, and exporter of Super Duplex Stainless Steel Condensate Pots in Houston, USA. Our advanced manufacturing facilities, strategically positioned in the USA, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Super Duplex Stainless Steel Condensate Pots

SDSS Type D Condensate Pots Price in Houston, S32750 Super Duplex Stainless Steel Type E Condensate Pot Manufacturer & Supplier in Los Angeles, Super Duplex Stainless Steel Condensate Pot Type F Supplier in Texas, Super Duplex Stainless Steel Type D Condensate Pot with Red Oxide Coated Manufacturer & Price in California, Super Duplex Stainless Steel Type E Condensate Pot with Red Oxide Coated Supplier in Houston, S32750 Super Duplex Stainless Steel Type F Condensate Pot Supplier In Houston, USA.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Super Duplex Stainless Steel Condensate Pots Supplier in Houston, USA

Paul Tube Fittings is a leading supplier and stockist of premium Super Duplex Stainless Steel Condensate Pots in Houston, USA. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Super Duplex Stainless Steel Condensate Pots Uses

Super Duplex Stainless Steel Condensate Pots find extensive application in high-pressure and corrosive environments, specifically in the power generation, chemical, and oil & gas industries. Their primary purpose is to gather and store temporarily condensate in steam or gas lines to avoid damaging sensitive instrumentation. The pots ensure measurement accuracy by separating instruments from direct process flow. Because of their high strength and resistance to corrosion, they are particularly useful in offshore platforms, refineries, and marine environments. Because they are strong and have a long service life, they can be utilized in critical process control systems and aggressive fluid handling configurations.
